TS 18S

Output Power

2500W peak@4Ω

Transducer Low:

18” (457 mm) woofer; 3” (76.2 mm) high-temperature voice coil

Frequency Response

35 Hz–100 Hz (-3 dB)

Frequency Range

27 Hz–111 Hz (-10dB)

Max SPL

137 dB (@1 m)

Connections

(2) XLR+1/4” (6.35 mm) inputs; (2) XLR outputs; (1) IEC power cable input

Controls

Volume control, signal/clip limiter with LED, speaker use button, proximity button, power switch with LED

Power:

IEC

Voltage: 100-120V, 50/60Hz; 220-240V, 50-60Hz

Consumption: 1600W

Fuse

100-120V, T15AL AC250V; 220-240V, T8AL AC250V

Protection:

Electronic clip, thermal and transducer overdrive protection

Enclosure:

Internally braced MDF cabinet; 36mm mounting pole socket on top panel

Mounting/Installation:

Standard 36 mm pole socket, flown application, suspended with integral M6 points, or in a wedge monitor position

Dimensions (height x width x depth)

26.7” x 20.9” x 24.7” / 678.2 x 530.9 x 627.4 mm

Weight:

93.0 lbs / 42.2 kg
